Rotary Drum Washing Machine AISI 304 SS

Rotary Drum Washing Machine Introduction:

• This rotary drum washer is widely proper for washing various fruit and vegetables, corn, seeds, coconut meat and larvae etc.It is also suitable for washing food package bags.
• Thanks to the cylinder covered with bristle brushes made of special hard polyurethane material, there are brushes for removing stones, mud and foreign materials on the product.
• A water pipe is placed inside the cylinder and compressed water is sprayed on the product that passes under it.
• The cylinder rotates on four rubber-covered wheels.
• During vegetables and fruits are rotating in the drum, the high pressure spraying water and brushes could clean all products thoroughly.
• There are anti-splashing containers on the sides, and there are 4 mica glass observation holes for vision warranty.
• There is a tank at the bottom of the cylinder that collects the spilled water and dirt.
• Materials are made of AISI 304 stainless steel. This machine is made of 304 stainless steel and mainly composed by motor, gear box, brushes, rotary drum and spraying pipes, suitable for various washing capacity.
• The output is 800-5000kgs/h.
• High pressure spraying pipe and cleaning nozzles to assure the best washing effect and high capacity.

Configuration:

• Material: Whole machine is made of 304 SS.
• Washing part: 2 stages: Pre-washing and rinsing with water recycle used.
• Rotary speed: VFD adjustable.
• Drum diameter: 700mm or customized
• Perforation size: 3/4/5/6/7/8/10/12/15/20mm or customized.
• Optional part: Screw conveyor inside/ Ozone generator / Brush / Electric heater

ماكينة غسيل بالاسطوانة الدوارة

• تتميز بوجود الأسطوانة المغطاة بفرشاة ذات شعيرات مصنوعة من مادة البولي يوريثين الصلبة الخاصة ، تستخدم لإزالة الأحجار والطين والمواد الغريبة العالقة على المنتج.
• يتم وضع أنبوب المياه داخل الأسطوانة ويتم رش الماء المضغوط على المنتج الذي يمر أسفله.
• تدور الأسطوانة على أربع عجلات مغطاة بالمطاط.
• توجد حاويات لمنع تناثر المياه على الجانبين ، وهناك 4 فتحات مراقبة زجاج الميكا لتأمين الرئية .
• يوجد خزان لتجميع الماء والأوساخ التي يتم سكبها تحت الحلة.
• المواد من الفولاذ المقاوم للصدأ AISI 304 الجودة.
