CM-X Series Continuous Motion Automatic Shrink Wrapping Machine

With its sophisticated movable sealing mechanism, the CM-X series facilitates high-speed operations, enabling you to cut down on labor and time expenses. The equipment finds wide applications across diverse sectors including but not limited to food products, cosmetics, chemicals, medical supplies, paints, printing, household appliances, and electrical and electronic materials. Our company is committed to providing the best possible assistance for shrink machines and continues to offer innovative solutions to meet your needs.

Application:

The conveyor transports products to the area where the movable sealing bar is located. Once there, the products are automatically wrapped with shrink film from the bottom and top, and then transferred to the shrink tunnel via the discharge band after being sealed by the hot sealing bar, which is controlled by a servo. Inside the tunnel, the polyethylene film tightly wraps around the product due to the temperature, and then takes the shape of the product as it cools with the help of a fan at the tunnel exit. This method of packaging not only enhances the product’s visual appeal but also safeguards it against abrasion, scratches, and dust during storage and transport.

Features:

– With an advanced movable sealing bar system, it is possible to work non-stop.
– The servo controlled hot sealing bar, which is positioned according to the height of the product, provides high speed packaging.
– Operators can easily adjust the package height and width via the operator panel, which automatically updates these parameters.
– The 7” LCD color touch screen makes it easy to set parameters and adjust settings.
– Capacity can be instantly read from the operator panel.
– The equipment comes with a motorized film drive mechanism and a servo controlled hot sealing bar system.
– The PID heat control system ensures that the sealings are provided with the right amount of heat.
– The tunnel entrances and exits are equipped with silicone curtains.
– The equipment has excellent thermal insulation, which reduces heat loss to a minimum.
– The cooling fan at the tunnel exit is used to cool and shape the product.
– The tunnel conveyor speed is adjustable to suit different requirements.
– The tunnel temperature can also be adjusted.
– It is easy and fast to exchange the film.
– The equipment comes with wheels that have brakes for easy transportation.
– An emergency button is provided for safety purposes.
– Installation is simple, and operation is easy.
– The equipment offers high shrinking speed, production efficiency, and package quality.
– The equipment conforms to CE standards and comes with a 2-year warranty (wearable parts not included).
– Spare parts are available for up to 7 years.
